How To Read Air Pressure Gauge

For accurate readings, you must first confirm the unit of measurement (PSI, Bar or MPa) on the dial. Before the system is pressurized, it must be confirmed that the pointer is zero and the reading must be observed after the system is stable. The most critical point is that the line of sight must be facing the dial when reading, and squint is strictly prohibited, otherwise the “parallax error” will make you misread the data every minute. In addition, if the pointer is shaking badly, it means that the system is vibrating or the pressure is unstable-at this time, changing the liquid-filled gauge usually solves the problem. Don’t forget, readings should always be checked against the safety limits of the equipment, and overpressure is no joke.

Step1: Figure Out Your Dial

Before doing it, see the dial unit clearly. I ‘ve seen too many novices on the scene mixing units: PSI (pounds per square inch): Most used in North America. Bar: The global metric unit. MPa (megapascals): high precision or frequent customers in industrial equipment. Special reminder: Many dials are double-scale now, so don’t read strings when reading.

Step2: Pre-check: Zero Is Crucial

Before connecting the pressure gauge to the system, be sure to take a look at whether the pointer is tightly pointing at “0. If the gauge does not return to zero without pressure, the gauge is mostly useless, either due to internal mechanical fatigue or a major calibration problem. If you take this kind of gauge to work, the numbers you read are all false information with offsets, which is a big taboo in engineering.

Step3: Avoiding Parallax

This is the most overlooked detail in the reading of a mechanical watch. There is a physical gap between the pointer and the dial. When you look at it from the side, the position of the pointer projected on the dial must be displaced. Therefore, my advice is: straighten your eyes so that your line of sight is perpendicular to the dial surface. This is the only reliable way to ensure accurate readings.

Step4: Signals Of Pressure Instability

Observe the pointer performance after pressurization. If the pointer is as stable as Mount Tai, then there is no problem. If it shakes violently, it means that there is either vibration or pulsating pressure in the pipeline. Frequent jitter not only makes you inaccurate reading, but also accelerates the wear of the internal components of the instrument. If this situation persists, change the filling meter decisively. The glycerin or silicone oil in it can play a good buffering role. Don’t put the meter in order to save this money.

Step5: Safety Guidelines: Control Limits

Reading is only the first step, and understanding the safety logic behind it is the manifestation of professionalism. Each device has a safety margin set by the manufacturer. You have to know where the “safe zone” of this equipment is. If the pointer approaches or exceeds the maximum allowable value, stop immediately. In this industry, prevention is more important than anything else.

In general, following these processes can not only extend the life of the equipment, but also protect your site safety. Remember, a properly maintained pressure gauge with accurate readings is the line of defense for your pressure control system.
