IMT Presta Tire Pressure Gauge adopts industrial ANSI B40.1 standard movement, which is specially designed to provide accurate measurement of 1% for high-pressure bicycle tires to ensure riding performance and safety. Hangzhou East Asia Instrument, as the source manufacturing plant, has more than 10 automated production lines, vertically integrates R & D and production links, eliminates middleman price difference, and provides highly competitive ex-factory prices and efficient batch delivery capabilities for global B- end customers.
Mainly used in high-end road bike maintenance, professional mountain bike shock adjustment, bicycle retail after-sales service and professional fleet equipment management.
industrial phosphor bronze bellows movement is adopted, and the measurement error is strictly controlled within +/-1.6, effectively avoiding the risk of tire burst caused by inaccurate reading of high-pressure pump, and improving professional competitive performance.
the case is made of 304 stainless steel and filled with high-viscosity silicone oil, which can absorb more than 90% of the physical impact and vibration to ensure stable readings in the bumpy maintenance workshop environment.
equipped with precision embedded pressure relief button, users can accurately adjust the pressure in units of 0.5 PSI without disassembling the air nozzle, meeting the strict requirements of professional technicians on small pressure difference.
high flexibility fluorine rubber sealing ring is embedded in the special joint, which can realize zero leakage connection even under high pressure 120 PSI, ensuring that the measured value truly reflects the real-time pressure in the tire.
The dial adopts coated luminous technology and is matched with a large-size digital scale. Even in a dimly lit track repair station or early morning outdoor environment, the technician can accurately read the data within 2 seconds.
the outer layer of the pressure guide tube is wrapped with multi-strand stainless steel braided mesh, the upper limit of pressure resistance is as high as 300 PSI, and the bending resistance life exceeds 10000 times, which significantly reduces the replacement cost of consumables for B- end users.
| Parameters | Technical Specifications Details |
| Product Model | IMT-PTG-01 Professional |
| Unit of measurement | PSI / Bar / kPa / kgf/cm² (four-position switching) |
| Measuring range | 0 – 160 PSI / 0 – 11 Bar |
| Core materials | 316L stainless steel interface and isolation membrane |
| Surface material | Tempered glass/polycarbonate optional |
| Connecting thread | M10 x 1 or customized according to customer requirements |
| Operating temperature | -20 degrees Celsius to 60 degrees Celsius |
| Calibration Standard | ASME B40.100 standard certification |
Compared with the common plastic tire pressure gauges on the market, IMT Presta Tire Pressure Gauge uses the industrial-grade membrane box technology of Hangzhou East Asia Instrument Core, which increases sensitivity by 40% at small scales. In particular, it has an absolute advantage in capturing subtle pressure changes below 20 PSI. In addition, IMT has incorporated a secondary calibration process into the production process. Every French tire pressure gauge leaving the factory is cycled through 5 pressure points, ensuring that in large-scale batch purchases, the consistency of the product is much higher than the industry average, and the re-repair rate remains below 0.3% for a long time.
are suitable for professional technicians who need to frequently perform precise tire pressure setting for various high-performance bicycles. The high durability of IMT tire pressure gauges can withstand the high intensity of daily use in the workshop.
are suitable for professional athletes and coaches who are extremely sensitive to tire pressure. Accurate readings help teams develop optimal grip and resistance plans for different track terrains.
for business customers looking for high quality OEM partners. The stable quality and compliance certification provided by IMT as a source factory can significantly reduce the access risk and after-sales cost in overseas markets.
are suitable for advanced riders who pursue the ultimate cycling experience. The laboratory-grade measurement accuracy provided by this product can meet its daily maintenance needs for expensive carbon fiber wheels and tubeless tires.
first unscrew the small nut at the end of the French air nozzle and gently press the air core to confirm ventilation.
Align the IMT tire pressure gauge connector with the air nozzle and press it to the end. Read the reading after the slight air leakage sound disappears.
If the pressure is too high, keep the connection state and press the pressure relief valve on the side of the watch case to observe the pointer drop to the target value in real time.
pull out the meter head vertically and tighten the air nozzle nut. After use, please put the tire pressure gauge into the protective box to avoid sharp drop and damage to accuracy.
certificate
Welcome to our Frequently Asked Questions page. We have compiled answers to common questions you may have, hoping to provide you with clear and quick solutions. If you cannot find the information you need here, please feel free to contact our customer support team.
IMT Presta Tire Pressure Gauge adopts industrial ANSI B40.1 standard movement, which is specially designed to provide accurate measurement of 1% for high-pressure bicycle tires to ensure riding performance and safety. Hangzhou East Asia Instrument, as the source manufacturing plant, has more than 10 automated production lines, vertically integrates R & D and production links, eliminates middleman price difference, and provides highly competitive ex-factory prices and efficient batch delivery capabilities for global B- end customers.
0-160 PSI
Measuring range
Class 1.6
Accuracy class
63mm
Dial diameter
industrial phosphor bronze bellows movement is adopted, and the measurement error is strictly controlled within +/-1.6, effectively avoiding the risk of tire burst caused by inaccurate reading of high-pressure pump, and improving professional competitive performance.
the case is made of 304 stainless steel and filled with high-viscosity silicone oil, which can absorb more than 90% of the physical impact and vibration to ensure stable readings in the bumpy maintenance workshop environment.
equipped with precision embedded pressure relief button, users can accurately adjust the pressure in units of 0.5 PSI without disassembling the air nozzle, meeting the strict requirements of professional technicians on small pressure difference.
high flexibility fluorine rubber sealing ring is embedded in the special joint, which can realize zero leakage connection even under high pressure 120 PSI, ensuring that the measured value truly reflects the real-time pressure in the tire.
The dial adopts coated luminous technology and is matched with a large-size digital scale. Even in a dimly lit track repair station or early morning outdoor environment, the technician can accurately read the data within 2 seconds.
the outer layer of the pressure guide tube is wrapped with multi-strand stainless steel braided mesh, the upper limit of pressure resistance is as high as 300 PSI, and the bending resistance life exceeds 10000 times, which significantly reduces the replacement cost of consumables for B- end users.
| Parameters | Technical Specifications Details |
| Product Model | IMT-PTG-01 Professional |
| Unit of measurement | PSI / Bar / kPa / kgf/cm² (four-position switching) |
| Measuring range | 0 – 160 PSI / 0 – 11 Bar |
| Core materials | 316L stainless steel interface and isolation membrane |
| Surface material | Tempered glass/polycarbonate optional |
| Connecting thread | M10 x 1 or customized according to customer requirements |
| Operating temperature | -20 degrees Celsius to 60 degrees Celsius |
| Calibration Standard | ASME B40.100 standard certification |
are suitable for professional technicians who need to frequently perform precise tire pressure setting for various high-performance bicycles. The high durability of IMT tire pressure gauges can withstand the high intensity of daily use in the workshop.
are suitable for professional athletes and coaches who are extremely sensitive to tire pressure. Accurate readings help teams develop optimal grip and resistance plans for different track terrains.
for business customers looking for high quality OEM partners. The stable quality and compliance certification provided by IMT as a source factory can significantly reduce the access risk and after-sales cost in overseas markets.
are suitable for advanced riders who pursue the ultimate cycling experience. The laboratory-grade measurement accuracy provided by this product can meet its daily maintenance needs for expensive carbon fiber wheels and tubeless tires.
first unscrew the small nut at the end of the French air nozzle and gently press the air core to confirm ventilation.
Align the IMT tire pressure gauge connector with the air nozzle and press it to the end. Read the reading after the slight air leakage sound disappears.
If the pressure is too high, keep the connection state and press the pressure relief valve on the side of the watch case to observe the pointer drop to the target value in real time.
pull out the meter head vertically and tighten the air nozzle nut. After use, please put the tire pressure gauge into the protective box to avoid sharp drop and damage to accuracy.
